CPU
- Support for Intel Core i7/Intel Core i5/Intel Core i3/Intel Pentium/Intel Celeron processors in the LGA1155 package
- L3 cache varies with CPU

CHIPSET
- Intel H61 Express Chipset

MEMORY
- 4× 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
- Dual channel memory architecture
- Support for DDR3 1333/1066/800 MHz memory modules
- Support for non-ECC memory modules

ONBOARD GRAPHICS
- Chipset:
1× D-Sub port
1× DVI-D port, supporting a maximum resolution of 1920×1200 (the DVI-D port does not support D-Sub connection by adapter)
1× HDMI port, supporting a maximum resolution of 1920×1200

AUDIO
- Realtek ALC889 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver

LAN
1× Atheros 8151 GbE LAN chip (10/100/1000 Mbit)

EXPASNION SLOTS
1× PCI Express x16 slot, running at x16
1× PCI Express x1 slot (All PCI Express slots conform to PCI Express 2.0 standard)
2× PCI slots

STORAGE INTERFACE
- Chipset: 4× SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices

USB
- Chipset: Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
- Etron EJ168 chip: Up to 2 USB 3.0/2.0 ports on the back panel

INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 4-pin ATX 12V power connector
4× SATA 3Gb/s connectors
1× CPU fan header
1× system fan header
1× front panel header
1× front panel audio header
2× USB 2.0/1.1 headers
1× parallel port header
1× serial port header
1× clearing CMOS jumper

BACK PANEL CONNECTORS
1× PS/2 keyboard port
1× PS/2 mouse port
1× D-Sub port
1× DVI-D port
1× HDMI port
2× USB 2.0/1.1 ports
2× USB 3.0/2.0 ports
1× RJ-45 port
3× audio jacks (Line In/Line Out/Microphone)

I/O CONTROLLER
- iTE IT8728 chip

H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU/system fan speed control
* Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install

BIOS
- 2× 32 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

UNIQUE FEATURES
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
- Support for Smart 6
- Support for Auto Green
- Support for ON/OFF Charge
- Support for Cloud OC
- Support for 3TB+ Unlock
- Support for TouchBIOS
- Support for Q-Share

OPERATING SYSTEM
- Support for Microsoft Windows 7/Vista/XP

FORM FACTOR
- Micro ATX Form Factor (24.4×22.5 cm)
