CPU

AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors

Supports AM3+ 32 nm CPU

Supports CPU up to 8 cores

Supports CPU up to 140 W

AMD Cool 'n' Quiet Technology

Chipset

AMD 990X/SB950

Memory

4 x DIMM, Max. 32GB, DDR3 2133(O.C.)/1866/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

* Refer to www.asus.com or user manual for the Memory QVL (Qualified Vendors Lists).

* Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows OS when you want to install 4GB or more memory on the motherboard.

* Due to CPU spec., AMD 100 series CPUs support up to DDR3 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz.

System Bus

Up to 5.2 GT/s HyperTransport 3.0

Multi-GPU Support

Supports NVIDIA Quad-GPU SLI Technology

Supports AMD Quad-GPU CrossFireX Technology

Expansion Slots

2 x PCIe 2.0 x16 (x16 or dual x8)

1 x PCIe 2.0 x16 (x4 mode, black)

2 x PCIe 2.0 x1

1 x PCI

Storage

AMD SB950 controller :

6 x SATA 6Gb/s port(s), gray

Support Raid 0, 1, 5, 10

ASMedia PCIe SATA controller :

2 x eSATA 6Gb/s port(s), red

LAN

Realtek 8111F, 1 x Gigabit LAN Controller(s)

Audio

Realtek ALC892 8-Channel High Definition Audio CODEC

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

Audio Feature :

-
