CPU
- AM3+ Socket:
* Support for AMD AM3+ FX processors
* Support for AMD AM3 Phenom II / AMD Athlon II processors

HYPER TRANSPORT BUS
- 5200 MT/s

CHIPSET
- North Bridge: AMD 990X
- South Bridge: AMD SB950

MEMORY
- 4× 1.5V DDR3 DIMM sockets supporting up to 32GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
- Dual channel memory architecture
- Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules (to support a DDR3 1866 MHz (and above) memory, you must install an AMD AM3+ CPU first)

AUDIO
- Realtek ALC889 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for Dolby Home Theater
- Support for S/PDIF Out

LAN
- 1× Realtek RTL8111E chip (10/100/1000 Mbit)

EXPANSION SLOTS
1× PCI Express x16 slot, running at x16 (PCIEX16) (for optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot)
1× PCI Express x16 slot, running at x8 (PCIEX8) (the PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot will operate at up to x8 mode)
1× PCI Express x16 slot, running at x4 (PCIEX4)
2× PCI Express x1 slots
* All PCI Express slots conform to the PCI Express 2.0 standard)
2× PCI slots

MULTI-GRAPHICS TECHNOLOGY
- Support for AMD CrossFireX and NVIDIA SLI technology (PCIEX16 and PCIEX8) (the PCIEX16 slot operates at up to x8 mode when AMD CrossFireX is enabled)

STORAGE INTERFACE
- South Bridge:
* 6× SATA 6Gb/s connectors supporting up to 6 SATA 6Gb/s devices
* Support for RAID 0, RAID 1, RAID5, RAID 10 and JBOD

USB
- South Bridge: Up to 14 USB 2.0/1.1 ports (8 ports on the back panel, 6 ports available through the internal USB headers)
- 2× Etron EJ168 chips: Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)

IEEE 1394
- VIA VT6308 chip: Up to 2 IEEE 1394a ports (1 port on the back panel, 1 port available through the internal IEEE 1394a header)

INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 8-pin ATX 12V power connector
6× SATA 6Gb/s connectors
1× CPU fan header
2× system fan headers
1× power fan header
1× front panel header
1× front panel audio header
1× S/PDIF Out header
3× USB 2.0/1.1 headers
1× USB 3.0/2.0 header
1× IEEE 1394a header
1× Trusted Platform Module (TPM) header
1× serial port header
1× clearing CMOS jumper

BACK PANEL CONNECTORS
1× PS/2 keyboard/mouse port
1× optical S/PDIF Out connector
1× IEEE 1394 port
8× USB 2.0/1.1 ports
2× USB 3.0/2.0 ports
1× RJ-45 port
6× audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)

I/O CONTROLLER
- ITE IT8720 chip

H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System/Power fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control (whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install)

BIOS
- 2× 32 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

UNIQUE FEATURES
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune (available functions in EasyTune may differ by motherboard model)
- Support for Easy Energy Saver
- Support for Smart Recovery
- Support for Auto Green
- Support for ON/OFF Charge
- Support for Cloud OC
- Support for 3TB+ Unlock
- Support for Q-Share

OPERATING SYSTEM
- Support for Microsoft Windows 7/ Vista/ XP

FORM FACTOR
- ATX Form Factor (30.5×24.4 cm)
