- Supports 4th Generation Intel Core processors
- GIGABYTE Ultra Durable 4 Plus Technology
- GIGABYTE Hybrid digital power engine
- GIGABYTE UEFI DualBIOS
- GIGABYTE 333 Onboard Acceleration (USB 3.0, SATA 3.0 & 3× USB Power)
- GIGABYTE On/Off Charge for USB devices
- LAN with high ESD Protection
- HDMI 1.4, DVI, D-SUB
- Intel Small Business Advantage

Specifikacija
CPU
- Support for Intel Core i7/Intel Core i5/Intel Core i3/Intel Pentium/Intel Celeron processors in the LGA1150 package
- L3 cache varies with CPU

CHIPSET
- Intel B85 Express Chipset

MEMORIJA
- 4× 1.5V DDR3 DIMM sockets supporting up to 32GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed
- Dual channel memory architecture
- Support for DDR3 1600/1333 MHz memory modules
- Support for non-ECC memory modules
- Support for Extreme Memory Profile (XMP) memory modules

AUDIO
- Realtek ALC887 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver

MREŽA
- Realtek G-LAN chip (10/100/1000 Mbit)

PROŠIRENJE
1× PCI Express x16 slot, running at x16 (The PCIEX16 slot conforms to PCI Express 3.0 standard)
2× PCI Express x1 slots (The PCI Express x1 slot conforms to PCI Express 2.0 standard)

STORAGE SUČELJE
- Chipset:
* 4× SATA 6Gb/s connectors (SATA3 0/1/2/3)
* 2× SATA 3Gb/s connectors (SATA2 4/5)

USB
- Chipset:
* 4× USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
* 8× USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

INTERNI I/O KONEKTORI
1× 24-pin ATX main power connector
1× 8-pin ATX 12V power connector
4× SATA 6Gb/s connectors
2× SATA 3Gb/s connectors
1× CPU fan header
1× system fan header
1× front panel header
1× front panel audio header
1× USB 3.0/2.0 header
2× USB 2.0/1.1 headers
1× serial port header
1× parallel port header
1× Clear CMOS jumper

STRAŽNJI KONEKTORI
1× PS/2 keyboard/mouse port
1× D-Sub port
1× DVI-D port
1× HDMI port
2× USB 3.0/2.0 ports
4× USB 2.0/1.1 ports
1× RJ-45 port
3× audio jacks (Line In, Line Out, Mic In)

I/O KONTROLER
- iTE I/O Controller Chip

H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install

BIOS
- 2 x 64 Mbit flash
- Use of licensed AMI EFI BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a

ZNAČAJKE
- Support for Q-Flash
- Support for Xpress Install
- Support for APP Center
* Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
@BIOS
* EasyTune, EZ Setup, USB Blocker, Smart TimeLock, Smart Recovery2
- Support for ON/OFF Charge

OPERATIVNI SUSTAV
- Podrška za Windows 8/7

FORM FACTOR
- Micro ATX Form Factor (22.6×19.3 cm)
