cpu
- Support for Intel Core i7/Intel Core i5/Intel Core i3/Intel Pentium/Intel Celeron processors in the LGA1155 package
- L3 cache varies with CPU

CHIPSET
- Intel Z68 Express Chipset

MEMORY
- 4× 1.5V DDR3 DIMM sockets supporting up to 32GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
- Dual channel memory architecture
- Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules
- Support for non-ECC memory modules
- Support for Extreme Memory Profile (XMP) memory modules

ONBOARD GRAPHICS
- Integrated Graphics Processor: 1× HDMI port, supporting a maximum resolution of 1920×1200

AUDIO
- Realtek ALC889 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for Dolby Home Theater
- Support for S/PDIF Out

LAN
1× Realtek RTL8111E chip (10/100/1000 Mbit)

EXPANSION SLOTS
1× PCI Express x16 slot, running at x16 (PCIE x16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIE x16 slot
1× PCI Express x16 slot, running at x8 (PCIE x8)
* The PCIE x8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIE x16 slot will operate at up to x8 mode
(All PCI Express x16 slots conform to PCI Express 3.0 standard)
* To support PCI Express 3.0, you must install an Intel 22nm CPU
3× PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 standard)
2× PCI slots

MULTI-GRAPHICS TECHNOLOGY
- Support for AMD CrossFireX / NVIDIA SLI technology
* The PCIE x16 slot operates at up to x8 mode when AMD CrossFireX / NVIDIA SLI is enabled

STORAGE INTERFACE
- Chipset:
2× SATA 6Gb/s connectors (SATA3_0-SATA3_1) supporting up to 2 SATA 6Gb/s devices
4× SATA 3Gb/s connectors (SATA2_2-SATA2_5) supporting up to 4 SATA 3Gb/s devices
* The SATA2_5 connector will become unavailable when the mSATA connector is installed with a solid state drive
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system performance of the RAID set may vary depending on the devices being connected
1× Marvell 88SE9172 chip:
2× SATA 6Gb/s connectors (GSATA3_6, GSATA3_7) supporting up to 2 SATA 6Gb/s devices
- Support for SATA RAID 0 and RAID 1

USB
- Chipset: Up to 14 USB 2.0/1.1 ports (8 ports on the back panel, 6 ports available through the internal USB headers)
- 2× Etron EJ168 chips: Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)

IEEE 1394
- VIA VT6308 chip: Up to 2 IEEE 1394a ports (1 port on the back panel, 1 port available through the internal IEEE 1394a header)

INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 8-pin ATX 12V power connector
4× SATA 6Gb/s connectors
4× SATA 3Gb/s connectors
1× mSATA connector
1× CPU fan header
2× system fan headers
1× power fan header
1× front panel header
1× front panel audio header
1× S/PDIF Out header
3× USB 2.0/1.1 headers
1× USB 3.0/2.0 header
1× IEEE 1394a header
1× serial port header
1× clearing CMOS jumper
1× Trusted Platform Module (TPM) header

BACK PANEL CONNECTORS
1× PS/2 keyboard/mouse port
1× HDMI port
1× optical S/PDIF Out connector
1× IEEE 1394 port
8× USB 2.0/1.1 ports
2× USB 3.0/2.0 ports
1× RJ-45 port
6× audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)

I/O CONTROLLER
- iTE IT8728 chip

H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System/Power fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install

BIOS
- 2× 32 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

UNIQUE FEATURES
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
- Support for Dynamic Energy Saver 2
- Support for Smart 6
- Support for Auto Green
- Support for eXtreme Hard Drive (X.H.D)
- Support for ON/OFF Charge
- Support for Cloud OC
- Support for 3TB+ Unlock
- Support for TouchBIOS
- Support for Q-Share

OPERATING SYSTEM
- Support for Microsoft Windows 7/Vista/XP

FORM FACTOR
- ATX Form Factor (30.5×24.4 cm)
