Key Features
INDUSTRIAL COMPLIANT WIRELESS LAN & LAN
- Compliant with IEEE 802.11n wireless technology capable of up to 150Mbps data rate
- Backward compatible with 802.11b/g standard
- Equipped with 10/100Mbps RJ-45 Ports for LAN & WAN, Auto MDI/ MDI-X supported

FIXED-NETWORK BROADBAND ROUTER
- Supported connection types: Dynamic IP/ Static IP / PPPoE / PPTP / L2TP
- Supports multiple sessions IPSec, L2TP and PPTP VPN passthrough
- Supports Virtual Server, DMZ and Port Forwarding for various networking applications
- Supports DHCP Server, UPnP, and Dynamic DNS

RF INTERFACE CHARACTERISTICS
- Built-in 12dBi Directional Antenna
- High Output Power Up to 600mW with multiple adjustable transmit power control
- Reserve RP-SMA Type Connector

OUTDOOR ENVIRONMENTAL CHARACTERISTICS
- IP-55 Enclosure
- Passive Power Over Ethernet Design
- Reset Button on PoE Injector
- Operating Temperature: -20 - 70 Degree C

MULTIPLE OPERATION & WIRELESS MODE
- Multiple Operation Modes: Bridge, Gateway, Ethernet Converter
- Multiple Wireless Modes: AP, Client CPE(WISP), WDS PtP, WDS PtMP, Repeater, Universal Repeater

SECURE NETWORK CONNECTION
- Supports Software Wi-Fi Protected Setup (WPS)
- Advanced security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK(TKIP/AES), and 802.1x Authentication
- Supports NAT firewall features, with SPI function to protect against DoS attacks
- Supports IP / Protocol-based access control and MAC Filtering

EASY INSTALLATION & MANAGEMENT
- Web-Based UI and Quick Setup Wizard for easy configuration
- Remote Management allows configuration from a remote site
- System status monitoring includes DHCP Client and System Log

Specification
HARDWARE SPECIFICATION
- Standard support:
* IEEE802.11b/g
* IEEE 802.11n
* IEEE 802.3 10Base-T
* IEEE 802.3u 100Base-TX
* IEEE 802.3x Flow Control
- Chipset: Ralink RT3050
- Memory: 16 Mbytes DDR SDRAM, 4 Mbytes Flash
- Interface:
* Wireless IEEE 802.11b/g/n
* LAN: 1×10/100Base-TX, Auto-MDI/MDIX
* WAN: 1×10/100Base-TX, Auto-MDI/MDIX
- Antenna:
* Internal (Default): 12dBi directional antenna (Vertical-Polarization) - H/V 60/30 degree
* External (Option): RP-SMA type Connector: Switchable by Software; For External Antenna Mode, attach antenna before power on
- Enclosure: IP55 waterproof case
- PoE:
* Passive PoE / 12V DC
* Reset Button on PoE Injector
* LAN RJ-45 Pin Assignment: PIN 4(+), PIN 7,8(-), PIN 5(Reset)
- Dimension (W×D×H): 225×77×60 mm
- Weight: 255g

WIRELESS INTERFACE SPECIFICATION
- Frequency Band: 2.4-2.4835GHz
- Modulation:
* Transmission/Emission Type: DSSS / OFDM
* Data modulation type: OFDM with BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, QPSK, CCK
- Data Rate:
802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back
802.11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
802.11n (20MHz): up to 72Mbps
802.11n (40MHz): up to 150Mbps
- Opt. Channel: Europe/ ETSI: 2.412~2.472GHz (13 Channels)
- RF Output Power:
802.11b: 27 +/- 1dBm
802.11g: 26 +/- 1dBm
802.11n: 22 +/- 1dBm
- Receiver Sensitivity:
802.11b: -93dBm
802.11g: -91dBm
802.11n: -89dBm
- Media Access Control: CSMA/CA
- Output Power Control: Range 1~100, default:100
- Power Requirements: 12V DC, 1A (switching)

WIRELESS MANAGEMENT FEATURES
- Wireless Mode: AP, Client, WDS PtP, WDS PtMP, WDS Repeater (AP+WDS), Universal Repeater (AP+Client)
- Channel Width: 20MHz / 40MHz
- Encryption Security:
* 64/128-bits WEP
* WPA, WPA-PSK
* WPA2, WPA2-PSK
* 802.1X
- Wireless Isolation: Able to isolate each connected wireless clients for independent access
- Wireless Security:
* Provides wireless LAN ACL (Access Control List) filtering
* Wireless MAC address filtering
* WPS (WIFI Protected Setup)
* Enable/Disable SSID Broadcast
- B/G Protection Mode: A protection mechanism prevents collisions among 802.11b/g modes
- Max. Wireless Client: 25
- Max. WDS AP: 4

SOFTWARE
- LAN: Built-in DHCP server supporting static IP address distributing, Supports UPnP, Supports IGMP Proxy, DNS Proxy, Supports 802.1d STP - Spanning Tree Protocol
- WAN Protocol: Static IP, DHCP (Dynamic IP), PPPoE, PPTP, L2TP
- VPN Passthrough: PPTP, L2TP, IPSec
- Operating Mode: Bridge, Gateway, Ethernet Converter (WISP)
- Firewall:
* NAT firewall with SPI (Stateful Packet Inspection)
* Built-in NAT server supporting Port Forwarding (Virtual Server), and DMZ
* Built-in firewall with Port / IP address / MAC / URL filtering
- Max. Wired Client: 60
- NTP: Network Time Management
- Management: Web UI, DHCP Client, Configuration Backup & Restore, Dynamic DNS
- Diagnostic tool: System Log

ENVIRONMENT
- Operation:
* Temp.: -20 - 70 Degree C
* Humidity: 10-95% non-condensing
- Storage:
* Temp.: -30 - 80 Degree C
Humidity: 5-95% non-condensing
