Explore 3D Printing
AnkerMake M5 prints 5X faster with 0.1mm accuracy.Built-in AI camera recognition system keeps your prints on track.Stop waiting and let us help you smartly and print quickly at every step.

5 faster printing
Precise 0.1 mm details
Built-in AI control camera
Hub connects several hoods
7x7 automatic adjustment
Automatically generated Timeplapse print shots
Aluminium structure
Print volume 235x235x250 mm3







Start 3D printing with the M5
See the M5 printer in action












Do it well and quickly

Print speed 500 mm/s
Print speed 50 mm/s

Powered by PowerBoost™High-speed precision is achieved thanks to PowerBoost™ technology, which optimizes energy with a Y-axis transmission system. PowerBoost™ uses a powerful stepping motor, double belt drive shaft and stabilized motion algorithm to squeeze out a lot of extra power for fast printing.Standard speed500mm/s Accelerated speedup to 2,500 mm/s2














3.1X extrusion
Higher multi-stage gear ratio
The foundation of fast printing starts with an improved multi-speed gear system with a reduction ratio of 9.37, which generates 0.8Nm of torque. Strong twisting pressure on the melting chamber, to make the extrusion faster.



1.5X melting
Larger heating block
The 60W heating rod quickly raises the temperature of the nozzles to 200°C with 1.5 times the efficiency of other printers. Heat ensures smooth filament discharge during fast printing at 250 mm/s.



1.3X cooling
More air intake
System of double hbark uses a pair of fans that push out 1.3 times more air than other printers at maximum speed. Cooling prevents straining and helps cool your model quickly.






Powerful Processing
The M5 is equipped with two processors, including the XBurst processor for intelligent 3D printing and the Marlin processor for routine processing. With added power, the M5 follows your prints so your model matches your design.

3-core heterogeneous CPU (1.2GHz ×2 + 240MHz)
Specialized for image recognition (VPU, ISP ×2, CIM)
Designed for Artificial Intelligence (AIoT)

Built-in intelligent camera

1080p Full HD resolution
Live tracking (in 720p)
Timelapse videos (in 1080p)
Frame rate: 30 fps















AI camera with recognition system
The AnkerMake cutter analyzes the 3D data of the model before printing, then the AI ??recognition system uses the powerful CPU XBurst to continuously check and compare throughout the process. p



Error detection, immediate notifications
Be protected against– Ridiculousness– Offset layers– 1st layer adhesion failure– Nozzle blockage




Control your printing 24/7
Check in whenever you want with a real-time view through the AnkerMake app.Even if it's 3 in the morning, you can check progress with adaptive light detection algorithms printing. Also, timelapse shots look better when there is no light.



Share your timelapse footage
Feel good about your creations and show them off with timelapse footage that's easy to share on social media.





Start printing anytime, anywhere
Whenever a moment of inspiration strikes, you'll be able to access your prints wherever you are. You can even track prints, pause jobs or change settings.





Alexa and Google Assistant



AnkerMake application



AnkerMake Slicer





Easy 3D printing at home
7x7 auto-adjustmentGive your prints precision with 7x7 auto-adjustment. Advanced algorithms calculate a virtual height map to start printing correctly. The only time you need to manually make any corrections is when you're upgrading to something larger, like a nozzle or PEI soft magnetic steel plate.Integrated design keeps your workspace organized Avoid tangled cables and multiple stray devices with 1 personal, cohesive design. The M5 consists of a base and portal frame, plus the Z-axis design hides any dangling wires from your view.Flexible and scratch-resistant panelsNo matter how big or small, removing the print is now simple by slightly bending the scratch-resistant soft magnetic PEI steel plate as it cools. And with the magnetic design of the heated base, the print base can be easily removed and put back in.Receive print status notificationsYou can choose how to find out when something changes with your 3D printing. See an LED 10m away, hear a beep or receive an app alert.Save material with instant alertsNever waste even the tiniest bit of filament again with alerts about low filament and errors. The M5 scans before and during printing to ensure your print will exactly match your requirements.Print large designs at high speedEnlarge your prints to a whopping 235 × 235 × 250 mm3 and watch the M5 get the job done quickly at 5 times the speed of conventional 3D printers.The 4.3-inch touch screen makes printing simpleSimplify the most common tasks with a smart, colorful LCD touch screen. You can also switch to night mode to help your eyes when you're working late.









Easy assembly
You don't need a degree to assemble the M5, just 15 minutes from the time the M5 arrives at your door.





Take all components out of the box



Tighten the screws at the bottom.



Start printing





Continues printing during power outages
Ensure safe storage of your print during power outages. If the power goes out, the printer saves the current layer and then resumes printing when the power is restored.






Print parameters

Volume (L×W×H): 235×235×250 mm3
Standard speed: 500 mm/s
Accelerated speed: 2,500 mm/s2
Operating speed: 50-500 mm/s
Printing accuracy: ±0.1 mm[1]
Nozzle diameter: 0.4 mm (also compatible with 0.2/0.6/0.8 mm)
Filament diameter: 1.75 mm
Printing materials: PLA/PETG/TPU/ABS
Temperature: max 260?
Heating plate: max 100?


Electronics

CPU: Dual XBurst (1.2GHz) + XBurst 0 (240MHz)
OS: Linux
EMMC: 8 GB
Connections: Wi-Fi (App, AnkerMake Slicer), Type-C USB Flash Drive, OTA Upgrades
Camera: Detection: AIRecognition, Real-Time Monitoring: up to 720p, Timelapse Video: 1080p, Timelapse Video FPS: 30fps, Night Vision: IR + LED
Screen: 4.3-inch, touch-sensitive
Remote control: AnkerMake App, AnkerMake Slicer
Voice control: Google Assistant, Amazon Alexa (check printing status)
Power: 350W
Voltage: AC 100-240V










Software

For slicing: AnkerMake Slicer (macOS, Windows), Simplify 3D, Ultimaker Cura, PrusaSlicer
Input file format: STL, OBJ
Supported operating systems: MacOS, Windows



Case

Device dimensions: 502x438x470 mm (without filament holder)
Net weight: 12.4 kg
Gross weight: 14.8kg
