Improve secured data and access protection.
Smart card technology finds popular applications in security and access control, financial transactions, medical records, loyalty programs, toll and vending collection, enterprise and single-user network sign-on and more that require secure information exchanges. Contact smart cards have a contact, or “chip," area with several contact pads that, when inserted into a Manhattan Smart Card Reader, can authenticate the user and safely transfer information between the card and host computer. Smart cards are utilized extensively in Europe and Asia, and the use of smart cards is growing in North and South America, replacing less secure and less reliable barcode ID and magnetic stripe cards to provide flexible and standard transactions and strong, tamper-resistant authentication with minimal human intervention.

Quick and Easy Installation
Ideal for desktop and notebook computers without built-in readers, the Manhattan Smart Card Reader is easily installed using any USB port and the included software and driver CD. Plug and play with Windows and Mac compatibility, it requires no external power supply or cables for a simple USB connection.

Standards and Certifications
FCC
CE
RoHS2
USB 2.0
CCID
EMV

Physical
Integrated USB type-A cable, 105 cm (41 in.)
Weight: 60 g (0.06 oz.)
Dimensions: 85 x 65 x 15 mm (3.35 x 2.6 x 0.6 in.)
Housing: ABS
IC: AU9540

General
CPU card: meets ISO 7816-1, 2, 3, 4 (supports T=0 and T=1 protocols), PC/SC version 1.0/2.0 standard and EMV 4.1
Memory card: synchronous 2-line, 3-line, SLE4418, 4428, 4432, 4442, AT88SC1608, 45D041 and I2C interface
PC/SC compliant 1.0/2.0, CT-API software library (SDK)
LED power and activity indicator
Power: voltage, USB 5 V + 5 %; consumption, 60 mA maximum
Durability, cycles: IC card, 200,000
Temperatures (°C): operation temperature, 0 – 50; storage, -35 – 70

System Requirements
USB-enabled PC or Mac system
Windows XP/Vista/7/8.1 or Mac or Linux compatible

Package Contents
Smart Card Reader
Quick Install Guide
CD includes drivers, API library and demonstration program with source code
