DFI Infinity Blood Iron P35-T2L, iP35, S.775, d-DDR2/1066MHz, PCIe, 8ch, G-LAN, S-ATAII
Proizvod nije dobavljiv. Potražite neke druge modele koji su zamijenili DFI Infinity Blood Iron P35-T2L, iP35, S.775, d-DDR2/1066MHz, PCIe, 8ch, G-LAN, S-ATAII
| Proizvođač: | DFI |
| Šifra: | 0080400 |
| Kataloški broj: | 13168 |
| Jamstvo: | 24 |
Prosječna ocjena:
0,00
| Glasova:
0
|
| Ocijeni
ovaj proizvod
|
SPECIFICATIONS
CPU
- LGA 775 socket for:
* Intel Core 2 Quad, Intel Core 2 Extreme, Intel Core 2 Duo, Intel Pentium D or Intel Pentium 4
- Supports Intel Enhanced Memory 64 Technology (EMT64T)
- Supports Enhanced Intel SpeedStep Technology (EIST)
- Supports Intel Hyper-Threading Technology
- Supports 1333*/1066/800MHz system bus speed (*Available only on CPUs that support 1333MHz FSB)
CHIPSET
- Intel chipset: Northbridge: Intel P35 Express chipset (with Intel Fast Memory Access technology)
EXPANSION SLOTS
- 1 PCI Express x16 slot
- 2 PCI Express x1 slots
- 3 PCI slots
BIOS
- Award BIOS
- 8Mbit flash memory
SYSTEM MEMORY
- Four 240-pin DDR2 DIMM sockets
- Supports DDR2 1066MHz (O.C 1200MHz)
- Supports dual channel (128-bit wide) memory interface
- Supports up to 8GB system memory
- Delivers up to 12.8Gb/s bandwidth
- Supports unbuffered x8 and x16 DIMMs
AUDIO
- Realtek ALC885 High Definition audio CODEC
- 8-channel audio output
- DAC SNR/ADC SNR of 106dB/101dB
- Full-rate lossless content protection technology
- Optical S/PDIF-out and coaxial RCA S/PDIF-out interfaces
HARDWARE MONITOR
- Monitors CPU/system/Northbridge temperature and overheat alarm
- Monitors Vcore/Vdimm/Vnb/VCC5/12V/V5sb/Vbat voltages
- Monitors the speed of the cooling fans
- CPU Overheat Protection function monitors CPU temperature and fan during system boot-up
(automatic shutdown upon system overheat)
POWER MANAGEMENT
- Ultimate 4-phase digital PWM with 12 MOSFETs
- ACPI and OS Directed Power Management
- ACPI STR (Suspend to RAM) function
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
- AC power failure recovery
LAN
- Marvell 88E8053 PCIE Gigabit LAN
- Fully compliant to IEEE 802.3 (10BASE-T), 802.3u(100BASE-TX)and 802.3ab(1000BASE-T)standards
IDE
- JMicron JMB368 PCI Express to PATA host controller
- Supports up to 2 UltraDMA 33/66/100Mbps IDE devices
Serial ATA
- 4 SATA ports
- SATA speed up to 3Gb
REAR PANEL I/O PORTS
1× mini-DIN-6 PS/2 mouse port
1× mini-DIN-6 PS/2 keyboard port
1× optical S/PDIF-out port
1× coaxial RCA S/PDIF-out port
6× USB 2.0/1.1 ports
1× RJ45 LAN port
Center/subwoofer, rear R/L and side R/L jacks
Line-in, line-out (front R/L) and mic-in jacks
I/O CONNECTORS
3× connectors for 6 additional external USB 2.0 ports
1× connector for an external COM port
1× front audio connector for line-out and mic-in jacks
1× CD-in internal audio connector
1× connector for IrDA interface
4× Serial ATA ports
1× 40-pin IDE connector
1× floppy connector
1× 24-pin ATX power connector
1× 8-pin 12V power connector
1× front panel connector
3× fan connectors
PCB
- 4 layers, ATX form factor
- 24.4×30.5cm
| Osnovne karakteristike | |
|---|---|
| Socket: | 775 |
