Interaktivna screenska plošča


Size: 86''
Osvetlitev ozadja: D-LED
Resolution: 3840 x 2160
Svetlost: 350cd/m2 (tip.)
contrastno ratio: 4000:1 (tip.)
response time: 8ms
Frekvenca osveževanja: 60Hz
viewing angle: 178°(V) / 178°(V)
Življenjska doba: 50.000 ur
Colour lestvica: 72%
colour screen: 1.07B(10bit)


system


OS: Android 8.0
Language: kitajski, angleški, poljski, nemški, francoski, italijanski, španski, finski, norveški, švedski, tajski, indonezijski, japonski


speaker


audio outputna Power: 2x15W


Connectivity


WI-FI: IEEE 802.11a/b/g/n/ac/ax (2.4G and 5G), IEEE 802.11a/b/g/n/ac (2.4G and 5G)
Bluetooth: BT5.1
input: HDMI(2.0) and x 2, DP(1.2a) and x 1, OPS (izbirno) x 1, LAN x 1, USB2.0 x 1, USB3.0 x 2, Type-C x 1, Touch x 1, RS232 and x 1, storitev x 1
output: HDMI(2.0) OUT x 1, S/PDIF OUT x 1, Audio OUT x 1


Power


Zahteve for power supply: AC 100 into ~ 240 V, 50/60 Hz
Energy Use without OPS: 370 W
Consumption into stanju pripravljenosti: <0,5 W


Dotik


Category zaznavanja: infrardeči frame on dotik
Površinska protection: steklo proti bleščanju
Infrardeči dotik: ?20 pixels
Natančnost dotika: 90 % (±1 mm)
Teoretični kliki: Neomejeno
Najmanjši predmet on dotik: ?2 mm
Windows 10/8/7, Android: Multi Touch


Fizično


Colour of the case: Black
Size izdelka (Š x into x G): 1955 × 1060 × 102 mm / 77,0 x 41,7 x 4,0 palca
Size paketa (Š x into x G): 2158 × 1370 x 302 mm / 85,0 x 53,9 x 11,9 palcev
Neto Weight: 54,5 kg / 120,17 lbs
Weight paketa: 72,5 kg / 159,86 lbs
VESA: 1000 × 600 mm, vijak 4-M8



Neobvezno


Osnovno: mobilni voziček, OPS


V škatli:


Navodila for uporabo
Pero x 2
yesljinec
Wireless Cast x 1 (izbirno)
power cable
Battery x 2
Stenski nosilec x 1

Interactive display panel


Size: 86''
Backlight: D-LED
Resolution: 3840 x 2160
Brightness: 350cd/m2 (typ.)
Contrast ratio: 4000:1 (typ.)
Response time: 8ms
Refresh rate: 60Hz
Viewing angle: 178°(V) / 178°(V)
Lifetime: 50,000 hours
Color scale: 72%
Screen colors: 1.07B(10bit)


System


OS: Android 8.0
Language: Chinese, English, Polish, German, French, Italian, Spanish, Finnish, Norwegian, Swedish, Thai, Indonesian, Japanese


Loudspeaker


Audio output power: 2x15W


Connectivity


WI-FI: IEEE 802.11a/b/g/n/ac/ax (2.4G and 5G), IEEE 802.11a/b/g/n/ac (2.4G and 5G)
Bluetooth: BT5.1
Input: HDMI(2.0) IN x 2, DP(1.2a) IN x 1, OPS (optional) x 1, LAN x 1, USB2.0 x 1, USB3.0 x 2, Type-C x 1, Touch x 1, RS232 IN x 1, Service x 1
Output: HDMI(2.0) OUT x 1, S/PDIF OUT x 1, Audio OUT x 1


Power


Power requirements: AC 100 V ~ 240 V, 50/60 Hz
Power consumption without OPS: 370 W
Standby consumption: <0.5W


Touch


Detection Type: Infrared Touch Frame
Surface protection: anti-glare glass
Infrared touch: ?20 points
Touch accuracy: 90% (±1mm)
Theoretical clicks: Unlimited
Smallest object to touch: ?2 mm
Windows 10/8/7, Android: Multi Touch


Physically


Case color: Black
Product Size (W x H x D): 1955 × 1060 × 102 mm / 77.0 x 41.7 x 4.0 inches
Package Size (W x H x D): 2158 x 1370 x 302 mm / 85.0 x 53.9 x 11.9 inches
Net weight: 54.5 kg / 120.17 lbs
Package weight: 72.5 kg / 159.86 lbs
VESA: 1000 × 600 mm, 4-M8 screw



Optional


Basic: mobile cart, OPS


In the box:


Instructions for use
Pen x 2
Remote control
Wireless Cast x 1 (optional)
Power cable
Battery x 2
Wall bracket x 1
