Compatibility:
Intel®:
Socket LGA775
Socket LGA1150
Socket LGA1151
Socket LGA1155
Socket LGA1156
Socket LGA1366
Socket LGA2011 / 2011-v3 (Square ILM)

AMD®:
Socket AM2
Socket AM2+
Socket AM3
Socket AM3+
Socket FM1
Socket FM2
Socket FM2+

Please note that an original backplate with screw mounting is needed for installation on mainboards with AMD sockets. Please check before buying if the backplate is fixed by screws (example)! If the backplate uses plastic-pins, mounting of this cooler is not possible.

Overall Dimensions:
171 x 147 x 140 mm / 5.79 x 5.51 x 6.73 in (including fan - more details)

Weight:
790 g / 27.86 oz

Accessory:
mounting parts for Intel and AMD sockets, screw driver, wrench, thermal grease, installation manual

Baseplate Material:
Nickel-plated copper (additional information)



Fan Specifications



Model Name:
GlideStream 140 PWM

Model-No.:
SY1425HB12M-P

Dimensions:
140 x 140 x 25 mm / 5.51 x 5.51 x 0.98 mm

Noise Level:
12.5 ~ 30.7 dBA

Air Flow:
29.90 ~ 97.18 CFM - 50.79 ~ 165.08 m3/h

Fan Speed:
400 (±300 upm) ~ 1.300 upm (±10%) (PWM-gesteuert)

Static Pressure:
0.98 ~ 10.0 Pa / 0.10 ~ 1.02 mmH2O

Bearing Type:
Gleitlager

max. Power Input:
4,44W

Voltage:
