• Universal input
• Overload protection, pulsing hiccup shutdown, auto recovery
• Protections: short circuit/over load/over voltage
• IP67, for indoor and outdoor installations
• UL1310 Class 2
• Fixed output voltage Input Voltage:
90...264V AC (47...63Hz)
127...370V DC
Input Inrush Current, Max.:
60A
Over Load Protection:
110...150%
Withstand Voltage (I/P-O/P):
3000V AC
Operating Temperature:
-30...+70°C
Weight:
400g
I/P = Input, O/P = Output


Part Nr.
UA
IA
PA
DUA
URN
h
[V]
[A]
[W]
[%]
[mVp-p]
[%]
LPV-60-5 5
0...8
40
8
80
76
LPV-60-12 12
0...5
60
5
120
83
LPV-60-15 15
0...4
60
5
120
83
LPV-60-24 24
0...2,5
60
5
150
86
LPV-60-36 36
0...1,67
60
5
150
86
LPV-60-48 48
0...1,25
60
5
150
86
UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Typ. Efficiency
Note
Devices only for use in equipment with another primary purpose such as photocopiers, overhead projectors and slide projectors or for scale illumination or indication purposes.
Suitable for indoor use and outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes.
You will find suitable High Power LED Modules starting at product group W1983.
Labelling
(only LPV-60-48), (except LPV-60-5, -48)
Terms of Delivery
Minimum order quantity: 1 PKU = 1 piece
Manufacturer

http://www.meanwell.com
