CPU

Intel Socket 1150 for the New 4th/4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors

Supports Intel 22 nm CPU

Supports Intel Turbo Boost Technology 2.0

* The Intel Turbo Boost Technology 2.0 support depends on the CPU types.

* Refer to www.asus.com for CPU support list

Chipset

Intel H81

Memory

4 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory *

Dual Channel Memory Architecture

Supports Intel Extreme Memory Profile (XMP)

* Hyper DIMM support is subject to the physical characteristics of individual CPUs.

* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

* Due to Intel chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz.

* Due to Intel chipset limitation, this motherboard can only support single-side memories when four modules are installed and they will run at the maximum transfer rate of DDR3 1066 MHz.

Graphic

Integrated Graphics Processor- Intel HD Graphics support

Multi-VGA output support : DVI/RGB ports

- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz

- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz

Maximum shared memory of 512 MB

Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider

Expansion Slots

1 x PCIe 2.0 x16 (x16 mode, gray)

3 x PCIe 2.0 x1

3 x PCI

Storage

Intel H81 chipset :

2 x SATA 6Gb/s port(s),
