CPU
- LGA 775 socket for: - Intel CoreTM2 Quad and Intel CoreTM2 Duo
- Supports Intel Enhanced Memory 64 Technology (EMT64T)
- Supports Enhanced Intel SpeedStep Technology (EIST)
- Supports Intel Hyper-Threading Technology
- Supports 1333/1066/800MHz FSB
Chipset
- Intel chipset:
* Northbridge: Intel P45 Express chipset Intel Fast Memory Access technology
* Southbridge: Intel ICH10R
System Memory
- Four 240-pin DDR2 DIMM sockets
- Supports DDR2 1200(O.C.)/1066/800/667 MHz
- Delivers up to 12.8Gb/s bandwidth
- Supports dual channel (128-bit wide) memory interface
- Supports non-ECC unbuffered DIMMs
- Supports up to 16GB system memory (Windows 32-bit operating system is unable to accurately detect more than 4GB system memory - Therefore, if you are using this operating system, we strongly recommend that you install a less than 3GB system memory)
Exspension Slots
- 2 PCI Express (Gen 2) x16 slots dimensionally with x8 transfer rate lanes only (8-lane ports)
* 2-way CrossFire: One slot operating at x8 (8-lane port) or two slots each operating at x8 (8-lane ports) bandwidth
- 1 PCI Express x1 slot
- 1 PCI slot
BIOS
- Award BIOS
- 8Mbit SPI flash BIOS
- CMOS Reloaded
Audio
- Realtek ALC885 High Definition audio CODEC
- 8-channel audio output
- DAC SNR/ADC SNR of 106dB/101dB
- Full-rate lossless content protection technology
- Optical S/PDIF-out and coaxial RCA S/PDIF-out interfaces
LAN
- Marvell 88E8053 PCIE Gigabit LAN controller
- Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX) and 802.3ab (1000BASE-T) standards
Serial ATA with RAID
- Intel Matrix Storage technology
- Supports up to 6 SATA devices
- SATA speed up to 3Gb/s
- RAID 0, RAID 1, RAID 0+1 and RAID 5
IDE
- JMicron JMB368 PCI Express to PATA host controller
- Supports up to 2 UltraDMA 33/66/100Mbps IDE devices
Rear Panel I/O
1× mini-DIN-6 PS/2 mouse port
1× mini-DIN-6 PS/2 keyboard port
1× optical S/PDIF-out port
1× coaxial RCA S/PDIF-out port
6× USB 2.0/1.1 ports
1× RJ45 LAN port
- Center/subwoofer, rear R/L and side R/L jacks
- Line-in, line-out (front R/L) and mic-in jacks
Internal I/O
3× connectors for 6 additional external USB 2.0 ports
1× connector for an external COM port
1× front audio connector
1× CD-in connector
1× IrDA connector
6× Serial ATA connectors
1× 40-pin IDE connector
1× floppy connector
1× 24-pin ATX power connector
1× 8-pin 12V power connector
1× front panel connector
3× fan connectors
1× download flash BIOS connector
EZ touch switches (power switch and reset switch)
Power Management
- ACPI and OS Directed Power Management
- ACPI STR (Suspend to RAM) function
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
- AC power failure recovery
Hardware Monitor
- Monitors CPU/system/Northbridge temperature and overheat alarm
- Monitors Vcore/Vdimm/Vnb/VCC5/12V/V5sb/Vbat voltages
- Monitors the speed of the cooling fans
- CPU Overheat Protection function monitors CPU temperature and fan during system boot-up - automatic shutdown upon system overheat
PCB
- 4 layers, microATX form factor
- 24.5×24.5 cm
