Matična ploča s775 Intel DP45SG, P45, DDR3, ATX
Proizvod nije dobavljiv. Potražite neke druge modele koji su zamijenili Matična ploča s775 Intel DP45SG, P45, DDR3, ATX
| Proizvođač: | Intel |
| Šifra: | 0080392 |
| Kataloški broj: | BLKDP45SG |
| Jamstvo: | 36 |
Prosječna ocjena:
0,00
| Glasova:
0
|
| Ocijeni
ovaj proizvod
|
Main Board Desktop - Processor
Chipset: Intel P45 Express
Provides Central Processor Unit: Intel Core2 Duo Processor
Intel Core2 Extreme Processor
Intel Core2 Quad Processor
Intel Pentium Dual-Core
Intel Celeron Dual-Core
Max. CPU Bus Clock Rate: 1333 MHz
CPU Socket Standard: Socket 775
CPU Maximum Quantity Supports: 1
Main Board Desktop - Memory
Memory Type: DDR3 SDRAM
Memory Form Factor: DIMM 240-pin
Memory Speed: 800MHz(PC3-6400)
1066MHz(PC3-8500)
1333MHz(PC3-10600)
Maximum Installable System Memory Storage Capacity: 16384 MB
Memory Slot Total Quantity: 4
Provides Error Checking Method: non-ECC
Memory Features: Two DDR Channels
Unbuffered
Main Board Desktop - Storage Controller
Storage Controller Type: RAID
SATA II
Storage Controller Form Factor: integrated
SATA Controller Interface Type: Serial ATA II/300
RAID Controller Interface Type: Serial ATA II/300
Supports Redundant Array of Independent Disks Level: Level 0
Level 1
Level 10
Level 5
Main Board Desktop - Audio Output
Audio Integrated: yes
Device Location: Integrated
Audio Chipset: IDT 92HD73E
Audio Output Mode: 7.1 Channel Surround
Compliant Audio Standards: Intel HD Audio
Main Board Desktop - Networking Specifications
LAN Integrated: yes
LAN Chipset: Intel 82567LF
Data Link Protocol Supports: Gigabit Ethernet/Fast Ethernet/Ethernet
Main Board Desktop - Slot Provided
PCI Express x16 Slot Quantity: 2
PCI Express x1 Slot Quantity: 2
PCI Slot Quantity: 3
Main Board Desktop - Interface Provided
Audio Line-In Interface Quantity: 1
Audio Line-Out Interface Quantity: 1
Microphone-In Interface Quantity: 1
Maximum USB Ports Quantity: 12
USB2.0 Interface Quantity: 6
IEEE-1394 Interface Quantity: 2
Serial Interface Quantity: 1
SATA II Interface Quantity: 5
LAN Interface Quantity: 1
Central/Bass Speaker Interface Quantity: 1
Rear Speaker Interface Quantity: 1
Side Speaker Interface Quantity: 1
ESATA II Interface Quantity: 1
Main Board Desktop - Mainboard Features
BIOS Features: ACPI 1.0b Support
DMI 2.0 Support
PnP Support
Hardware Monitoring: CPU Fan Tachometer
CPU Temperature
CPU Voltage
Main Board Desktop - Software
Software Included: Drivers
Main Board Desktop - Miscellaneous
Package Type: Retail
Cable Included: Serial ATA Cable
Included Accessories: I/O Shield
Main Board Desktop - Dimensions&Weight
Form Factor: ATX
Height: 244 mm
Width: 295 mm
Nominal Weight: 0.91 kg
Main Board Desktop - Environment
Maximum Operating Ambient Temperature: 55 °
Minimum Operating Ambient Temperature: 0 °
Maximum Non-Operating Ambient Temperature: 70 °
Minimum Non-Operating Ambient Temperature: -20 °
| Osnovne karakteristike | |
|---|---|
| Socket: | 775 |
