CPU
- Support for AM3 processors: AMD Phenom II/AMD Athlon II
HYPER TRANSPORT BUS
- 5200 MT/s
CHIPSET
- North Bridge: AMD 785G
- South Bridge: AMD SB710
MEMORY
- 4× 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
- Dual channel memory architecture
- Support for DDR3 1800 (OC)/1666/1333/1066 MHz memory modules
ONBOARD GRAPHICS
- Integrated in the North Bridge
* 1× D-Sub port
* 1× DVI-D port (The DVI-D port does not support D-Sub connection by adapter; Simultaneous output for DVI-D and HDMI is not supported)
* 1× HDMI port (Simultaneous output for DVI-D and HDMI is not supported)
AUDIO
- Realtek ALC889 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for Dolby Home Theater; Support for S/PDIF In/Out; Support for CD In
LAN
- Realtek 8111D chip (10/100/1000 Mbit)
EXPANISOMN SLOTS
1× PCI Express x16 slot, running at x16 (PCIEX16) (The PCI Express x16 slot conforms to PCI Express 2.0 standard)
1× PCI Express x1 slot
2× PCI slots
STORAGE INTERFACE
- South Bridge: 1× IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices; 5× SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices; 1× eSATA 3Gb/s port on the back panel supporting up to 1 SATA 3Gb/s device; Support for SATA RAID 0, RAID 1, RAID 10 and JBOD
- iTE IT8720 chip: 1× floppy disk drive connector supporting up to 1 floppy disk drive
USB
- Up to 12 USB 2.0/1.1 ports (Note 4) (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)
- NEC D720200F1 chip: Up to 2 USB3.0 ports on the back panel
IEEE 1394
- T.I. TSB43AB23 chip: Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 8-pin ATX 12V power connector
1× floppy disk drive connector
1× IDE connector
5× SATA 3Gb/s connectors
1× CPU fan header
1× system fan header
1× front panel header
1× front panel audio header
1× CD In connector
1× S/PDIF In/Out header
3× USB 2.0/1.1 headers
1× IEEE 1394a header
1× serial port header
1× clearing CMOS jumper
BACK PANEL CONNECTORS
1×PS/2 keyboard port or PS/2 mouse port
1× D-Sub port
1× DVI-D port (Note 2)(Note 3)
1× HDMI port (Note 3)
1× optical S/PDIF Out connector
1× eSATA 3Gb/s port
1× IEEE 1394a port
4× USB 2.0/1.1 ports
2× USB 3.0/2.0 ports
1× RJ-45 port
6× audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O CONTROLLER
- ITE IT8720 chip
H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control (Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install)
BIOS
- 2× 8 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
UNIQUE FEATURES
- Support for BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune (Available functions in EasyTune may differ by motherboard model)
- Support for Easy Energy Saver
- Support for Time Repare
- Support for Q-Share
OPERATING SYSTEM
- Support for Microsoft Windows 7/Vista/ XP
FORM FACTOR
- Micro ATX Form Factor (24.3×24.3 cm)
