MB DFI Infinity Blood Iron P35-T2RL, iP35, S.775, d-DDR2/800MHz, PCIe, 8ch, G-LAN, RAID
Proizvod nije dobavljiv. Potražite neke druge modele koji su zamijenili MB DFI Infinity Blood Iron P35-T2RL, iP35, S.775, d-DDR2/800MHz, PCIe, 8ch, G-LAN, RAID
| Proizvođač: | DFI |
| Šifra: | 0080213 |
| Kataloški broj: | Infinity Blood Iron P35-T2RL |
| Jamstvo: | 24 |
Prosječna ocjena:
0,00
| Glasova:
0
|
| Ocijeni
ovaj proizvod
|
SPECIFICATION
CPU
- LGA 775 socket for: Intel CoreTM2 Quad, Intel CoreTM2 Extreme, Intel CoreTM2 Duo, Intel Pentium D or Intel Pentium 4
- Supports Intel Enhanced Memory 64 Technology (EMT64T)
- Supports Enhanced Intel SpeedStep Technology (EIST)
- Supports Intel Hyper-Threading Technology
- Supports 1333*/1066/800MHz system bus speed (*Available only on CPUs that support 1333MHz FSB)
CHIPSET
Intel chipset
- Northbridge: Intel P35 Express chipset (with Intel Fast Memory Access technology)
- Southbridge: Intel ICH9R
MEMORY
- Four 240-pin DDR2 DIMM sockets
- Supports DDR2 667/800 MHz DIMMs
- Supports dual channel (128-bit wide) memory interface
- Supports up to 8GB system memory
- Delivers up to 12.8Gb/s bandwidth
- Supports unbuffered ×8 and ×16 DIMMs
EXPANSION SLOTS
- 1 PCI Express x16 slot
- 2 PCI Express x1 slots
- 3 PCI slots
BIOS
- Award BIOS
- 8Mbit flash memory
POWER MANAGEMENT
- ACPI and OS Directed Power Management
- ACPI STR (Suspend to RAM) function
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
- AC power failure recovery
HARDWARE MONITOR
- Monitors CPU/system/Northbridge temperature and overheat alarm
- Monitors Vcore/Vdimm/Vnb/VCC5/12V/V5sb/Vbat voltages
- Monitors the speed of the cooling fans
- CPU Overheat Protection function monitors CPU temperature and fan during system boot-up - automatic shutdown upon system overheat
AUDIO
- Realtek ALC885 High Definition audio CODEC
- 8-channel audio output
- DAC SNR/ADC SNR of 106dB/101dB
- Full-rate lossless content protection technology
- Optical S/PDIF-out and coaxial RCA S/PDIF-out interfaces
LAN
- Marvell 88E8053 PCIE Gigabit LAN
- Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX) and 802.3ab (1000BASE-T) standards
IDE
- JMicron JMB368 PCI Express to PATA host controller
- Supports up to 2 UltraDMA 33/66/100Mbps IDE devices
Serial ATA with RAID
- 6 SATA ports
- SATA speed up to 3Gb/s
- RAID 0, RAID 1, RAID 0+1 and RAID 5
REAR PANEL I/O PORTS
- 1 mini-DIN-6 PS/2 mouse port
- 1 mini-DIN-6 PS/2 keyboard port
- 1 optical S/PDIF-out port
- 1 coaxial RCA S/PDIF-out port
- 6 USB 2.0/1.1 ports
- 1 RJ45 LAN port
- Center/subwoofer, rear R/L and side R/L jacks
- Line-in, line-out (front R/L) and mic-in jacks
I/O CONNECTORS
- 3 connectors for 6 additional external USB 2.0 ports
- 1 connector for an external COM port
- 1 front audio connector for line-out and mic-in jacks
- 1 CD-in internal audio connector
- 1 connector for IrDA interface
- 6 Serial ATA ports
- 1 40-pin IDE connector
- 1 floppy connector
- 1 24-pin ATX power connector
- 1 8-pin 12V power connector
- 1 front panel connector
- 3 fan connectors
PCB
- 4 layers, ATX form factor
- 24.4×30.5 cm
| Osnovne karakteristike | |
|---|---|
| Socket: | 775 |
