Features
- UPS in OnLine Double Conversion technology
- Stand-alone and 19" in one cabinet (Unicase)
- Compatible with power/diesel generators
- UPS with Input Power Factor Corrector (PFC)
- Complete protection circuitry
- User friendly LCD display
- Option slot for greater fl exibility
- Built-In automatic and manual by-pass
- TCP/IP - SNMP kit for network integration (optional)
- 24-month guarantee

Technical Specifications
- Power: 2000VA (1400W)

INPUT
- Nominal Input Voltage: 160 - 280 Vac (Single Phase)
- Input Frequency: 50 / 60 Hz (+/-5% Auto Sensing)
- Input Connections: (×1) IEC 320

OUTPUT
- Output Voltage (mains mode): 200/220/230/240 Vac (Dip Switch Selectable)
- Output Voltage (battery mode): 200/220/230/240 Vac (Dip Switch Selectable)
- Output Frequency: 50 / 60 Hz +/-5%
- Output Format: Sine Wave, OnLine DC Technology
- Output Connections: (×6) IEC 320
- Intervention Time (Typical): 0 ms
- Efficiency (fully charged battery): > 83% (AC to AC)

BATTERIES AND BACKUP TIME
- Battery Type: (×6) 12 V - 7 Ah (Maintenance-free Sealed Lead-Acid)
- Typical Recharge Time: 8 h (to 90%)
- Backup Time (100% load): 8 min.

CONTROLS AND COMMUNICATION
- Front Panel: LCD Display
- Audible Alarms: On Battery, Low Battery, Overload
- Interface Ports: USB, RS-232, TCP/IP - SNMP (optional)
- Software: Power UPSEye XP (free download)
- ADSL Line Protection: Yes
- Easy Swap Batteries: Yes

- Operating Temperature: 0 - 40 C
- Storage Temperature: -20 - 50 C
- Operative Relative Humidity: 0 - 95% (Non Condensing)
- Noise (online) v 1 mt.: < 45 dBA
- Dimensions (H×W×D): 443×88×662 mm
- Net Weight: 27.4 kg
- Color: Black
