PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.



CPU Socket LGA 1200
The CPU socket is an important factor in selecting the board; the CPU board must be exactly compatible with the CPU that you want to install with the board. Irrespective of the fact that the CPU fits the socket of the motherboard also the support of this CPU has to be taken into account. For verifying which CPUs are supported by the selected motherboard you should visit the website of the manufacturer of the motherboard, find the CPU support section of the relevant motherboard and verify that the specification of this particular board provides for the support of the CPU that you have selected.
Form factor Micro ATX

The physical size of the motherboard. offers ATX (full size board), mATX (micro ATX) (a board of reduced size) and miniATX size motherboards. Within the housing of an ATX size computer it is possible to place both ATX and mATX motherboard, however, in the mATX housing it is not possible to place an ATX board.

The ATX board has at least 3 memory slots and at least 5 local slots PCI, which means that a well functioning powerful computer can be built on this board. However, a home or office computer does not need this high number of slots, therefore also microATX will be suitable.

The connector of the power supply unit of the motherboard is the power source socket which are currently of ATX and ATX2.0 standard. ATX is an older standard with a 20pin connector (20 "pins"), and ATX2.0 has 4 additional pins (20+4). The motherboards of ATX standard can operate with a ATX2.0 power supply unit (PSU), however the mother board of ATX2.0 standard requires an ATX2.0 power supply unit.

Form-factor is rather a recommendation. However, prior to buying a mother board you should verify the compatibility of the housing size to the motherboard size and its power supply connector.
Random-access memory (RAM)
Type : DDR4
Ports and equipment
SATA 1/2 Ports 0
SATA (Serial ATA) is the currently dominating standard for connecting HDDs. One SATA HDD or SATA DVD device can be connected to one SATA port.Prior to buying the motherboard you should verify if the number of SATA ports allows you to connect all the necessary SATA discs.
USB Ports : 4
USB3.0 (3.1 Gen1) Ports : 2
D-Sub : 1
HDMI : 1
Wireless connections
Built-in Wi-Fi : Nav
More detailed specification
BIOS - Clear CMOS jumper - Y
Brand - MSI
BrandPartCode - PRO H410M-B
category - Mainboards Intel Mainboards
Category - Motherboards
code - 7D82-001R
ean - 4719072917395
Expansion slots - Number of M.2 (M) slots - 1
Expansion slots - PCI Express x1 (Gen 3.x) slots - 1
Expansion slots - PCI Express x16 (Gen 3.x) slots - 1
Features - Audio chip - Realtek ALC892 / Realtek ALC897
Features - Audio output channels - 7.1 channels
Features - Component for - PC
Features - Motherboard chipset - Intel H510
Features - Motherboard chipset family - Intel
Features - Motherboard form factor - micro ATX
Features - Number of mounting holes - 6
Features - Windows operating systems supported - Windows 10 x64
GTIN - 4719072917395
Internal I/O - 12V power connector - Y
Internal I/O - ATX Power connector (24-pin) - Y
Internal I/O - Chassis intrusion connector - Y
Internal I/O - CPU fan connector - Y
Internal I/O - Front panel audio connector - Y
Internal I/O - Number of chassis fan connectors - 2
Internal I/O - Number of SATA III connectors - 4
Internal I/O - TPM connector - Y
Internal I/O - USB 2.0 connectors - 1
Internal I/O - USB 3.2 Gen 1 (3.1 Gen 1) connectors - 1
LongDesc - PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.
USER FRIENDLY DESIGN
MSI motherboards feature tons of convenient and smart design for DIY users, countless system tuning and troubleshooting tools are at your disposal to push your system to new heights and satisfy even the most demanding tweaker. Makes it so easy to install your own motherboard without any issue.
FULLY CONTROLLABLE IN BIOS AND SOFTWARE
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.
EZ DEBUG LED
Ran into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.
LongProductName - LGA1200, Intel H510, 2x DDR4, VGA, HDMI, 4x SATA III, M.2, USB 3.2, m-ATX, 236x202 mm
LongSummaryDescription - MSI PRO H410M-B. Processor manufacturer: Intel, Processor socket: LGA 1200, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium®. Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2,SATA III, Supported storage drive types: HDD & SSD. Ethernet interface type: Gigabit Ethernet. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel
Memory - Maximum internal memory - 64 GB
Memory - Memory channels - Dual-channel
Memory - Memory slots type - DIMM
Memory - Non-ECC - Y
Memory - Number of memory slots - 2
Memory - Supported memory clock speeds - 2133,2666,2933 MHz
Memory - Supported memory types - DDR4-SDRAM
Memory - Unbuffered memory - Y
name - MSI PRO H410M-B, Intel H510 Mainboard - Sockel 1200
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Y
Network - Wi-Fi - N
Packaging content - Cables included - SATA
Packaging content - Drivers included - Y
Processor - Compatible processor series - Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium®
Processor - Maximum number of SMP processors - 1
Processor - Processor manufacturer - Intel
Processor - Processor socket - LGA 1200
ProductName - PRO H410M-B
Rear panel I/O ports - Ethernet LAN (RJ-45) ports - 1
Rear panel I/O ports - HDMI ports quantity - 1
Rear panel I/O ports - HDMI version - 1.4
Rear panel I/O ports - PS/2 ports quantity - 1
Rear panel I/O ports - USB 2.0 ports quantity - 4
Rear panel I/O ports - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Rear panel I/O ports - VGA (D-Sub) ports quantity - 1
ShortSummaryDescription - MSI PRO H410M-B, Intel, LGA 1200, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium®, DDR4-SDRAM, 64 GB, DIMM
Storage controllers - Supported storage drive interfaces - M.2,SATA III
Storage controllers - Supported storage drive types - HDD & SSD
Title - MSI PRO H410M-B motherboard Intel H510 LGA 1200 micro ATX
URL - https://www.msi.com/Motherboard/PRO-H410M-B
WarrantyInfo -
Weight & dimensions - Depth - 202 mm
Weight & dimensions - Width - 236 mm
