Key Features
- Cost-effective VDSL2 CO / CPE bridge solution
- One box design, CO / CPE selectable via DIP Switch
- Defines asymmetric (Plan 998) and symmetric (Plan 997) band plans for the transmission of upstream and downstream signals
- Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards
- DMT (Discrete Multi-Tone) line coding
- Half duplex Back pressure and IEEE 802.3x Full Duplex Pause frame flow control
- Built-in POTS splitter to share voice and data
- Two RJ-11 connectors for each VDSL port, one for VDSL connection and one for POTS connection
- Voice and data communication can be shared simultaneously based on the existing telephone wire
- Supports up to 1536 bytes packet size, IEEE 802.1Q VLAN tag transparent
- VDSL2 stand-alone transceiver for simple bridge modem application
- Advantage of minimum installation time (Simply as Plug-and-Play)
- Selectable target band plan and target SNR margin
- Supports extensive LED indicators for network diagnostics
- Co-work with PLANET MC family Media Chassis (MC-700 / 1500/ 1500R)
- Compact in size, easy installation
Specification
HARDWARE SPECIFICATION
- Ports:
* 10/100Base-TX: 1 RJ-45, Auto-negotiation and Auto-MDI / MDI-X
* VDSL: 1 RJ-11, female Phone Jack
* PHONE: 1 RJ-11, Built-in splitters for POTS connection
- DIP Switch: 4 position DIP switch
- Functionality:
* CO / CPE mode select
* Selectable fast and interleaved mode
* Selectable target band plan
* Selectable target SNR mode
- Encoding:
* VDSL-DMT: ITU-T G.993.1 VDSL; ITU-T G.997.1; ITU-T G.993.2 VDSL2 (Profile 17a Support)
- LED Indicators:
* One Power
* 3 for RJ-11 / VDSL2 WAN: Green, LNK / ACT; Green, CO mode; Green, CPE mode
* 2 for per RJ-45 10/100Base-TX port: Green, LNK / ACT; Green, Speed
- Cabling Type:
* 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
* 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
* VDSL: twisted-pair telephone wires (AWG24 or better) up to 1.6km
- Performance: Full VDSL2 bandwidth up to: (Down Stream / Up Stream)
* Asymmetric Mode:
200m -> 100/55Mbps
400m -> 90/50Mbps
600m -> 70/40Mbps
800m -> 60/25Mbps
1000m -> 45/15Mbps
1200m -> 35/10Mbps
1400m -> 30/6Mbps
1600m -> 25/4Mbps
* Symmetric Mode:
200m -> 90/90Mbps
400m -> 90/90Mbps
600m -> 70/70Mbps
800m -> 55/50Mbps
1000m -> 40/35Mbps
1200m -> 30/25Mbps
1400m -> 25/20Mbps
1600m -> 20/15Mbps
- Dimension (W×D×H): 97×69×26 mm
- Weight: 0.4 kg
- Power Requirement: 5V DC 2A
- Operating Temperature: 0-50 Degree C
- Storage Temperature: -25-70 Degree C
- Operating Humidity: 10-90%, relative humidity, non-condensing
- Storage Humidity: 10-90%, relative humidity, non-condensing
STANDARD CONFORMANCE
- Regulation Compliance: FCC Part 15 Class A, CE
- Standards Compliance:
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
ITU-T
* G.993.1 (VDSL)
* G.997.1
* G.993.2 VDSL2 (Profile 17a )
