Features
- Shares data and Internet access for Stations, connecting Internet through PPPoE on demand and disconnecting when idle
- Supports TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
- Provides double-bandwidth access and supports Load Balancing
- Backups connections automatically for each other
- Specifies priority channels according to source or destination IP addresses, distributing flexibly Internet resource and services from different ISPs
- Built-in NAT and DHCP server supporting static IP address distributing
- Built-in firewall supporting IP address filtering, Domain Name filtering, and MAC address filtering
- Supports Port Bandwidth Control, Port Mirror, Port-based VLAN for LAN ports
- Supports Virtual Server, Special Application, and DMZ host
- Supports UPnP, Static Routing, VPN pass-through
- Supports connecting/disconnecting Internet on a specified time of day
- Supports access control based on time of day, parents and network administrators can establish restricted access policies for children or staffs
- Supports Flow Statistics
- Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter
- Supports web-based firmware upgrade
- Supports Remote and Web management
- Desktop or rack-mountable steel case

Specifications
SOFTWARE SPECIFICATION
- Standards and Protocols: IEEE 802.3, 802.3u, 802.3z, 802.3ab, 802.3x, 802.1x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS
- Basic Function:
* DHCP Server
* DHCP Client
* MAC Address Modify/Clone
* VPN Pass-through
* Static Routing
* Dynamic DNS
- QoS:
* IP-Based QoS
* Port Bandwidth Control
* IP Connection Session Control
* IP Bandwidth Control
* Connection Session List
- Port Settings:
* Port-based VLAN
* Port Mirrorring
* Flow Statistics
* LAN and WAN Port Setting
- Forwarding Rules:
* Virtual Server
* Special Application
* Static Routing
* DMZ Host
* UPnP
- Firewall Function:
* Firewall Rules Setting
* MAC Address Filtering
* Domain Name Filtering
* IP/MAC Address Binding
* Ignore Ping Packet From WAN Port
* DoS Protection
* Scan Protection
* IP Packets Containing Options
* Suspicious Package Detection
- System Function:
* Remote Management
* System Log
* Configuration File Uploading and Downloading
* Web Upgrade
* HTTPS Configuration
- New Dual-WAN Function:
* Flow Statistics
* WAN Load Balancing: Bandwidth Occupancy; WAN IP Tracing
* WAN Bandwidth Percentage Display
* LAN IP Statistics
* Detecting Online: ICMP Detecting; DNS Detecting

HARDWARE SPECIFICATION
- Solution: Intel IXP Network Processor, Multi-CPU distributed processing, main frequency up to 266MHz
- Ports:
* LAN: 3× 10/100M Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
* WAN: 2× 10/100M Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
* 1 Console (RS232 DB9 Male)
- Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
* 100BASE-TX: UTP category 5, 5e cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
- LED Indicators:
* LAN/WAN: Link/Act, 100Mbps
* Else: Power, M1, M2
- Dimensions (W×D×H): 294×180×44 mm
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Power and Consumption:
* Input: 100-240VAC; 50/60Hz
* Consumption: 4.1W (Max)
