Super high resolution with 4 megapixels: The VIGI C240I camera has a resolution of 4 megapixels – more than enough pixels to capture some of the more discreet details.People and vehicle classification: distinguish people and vehicles from others objects so that you receive more accurate event notifications.Smart Detection: Receive notifications and check sources when someone crosses the border, enters the area you set, obstructs the camera, or removes/leaves objects.IK10 Vandal-Resistant & IP67 Waterproof: This VIGI dome camera with vandal-resistant rugged housing and waterproof design is built to withstand vandalism and harsh environments with rain and dust for constant security anywhere, anytime.H.265+ : without using extra bandwidth, your cameras transmit compressed crystal clear video to save disk space, lighten network load and reduce monitoring costs without sacrificing image quality.Smart video enhancement: professional VIGI technologies process videos , to greatly improve their quality, which is crucial for your monitoring, including smart IR, WDR, 3D DNR and night vision.PoE/12V DC: Two types of power supply not only provide you with more convenience, but also extremely easy wiring.2.8/4mm lens: Whether you need a wide-angle lens to cover indoor spaces or a higher millimeter lens for longer distances in open spaces, the C240I has two different types of lenses to better suit your security needs.Flexible Management: Take full control of your security through four management modes: Web UI, NVR UI, VIGI App and VIGI Security Manager.
CAMERAImage sensor 1/3” CMOS with progressive scanShutter speed 1/3 to 1/10000 sSlow shutter Yes Minimum illumination color: 0.1 lux; 0 lux with IRDay/night mechanism IR Cut FilterDay/night switching unified/scheduled/automaticLens 2.8mm/ 4mmAperture 2.8mm : F2.24mm: F2.2M12 Lens Mount2.8mm Angle of View: 88.8°/48.9°/106.5° (H/ H/D)4mm: 75.1°/41.5°/88.7° (H/V/D)IR working distance 30mDigital noise reduction 3D DNRWDR DWDRIP67 weatherproof ratingLENSFixed focus lens typeFocal length 2.8mm/4mmAperture 2.8mm: F2.24mm: F2.2FOV 2.8mm:Horizontal angle of view: 88.8°, Vertical angle of view: 48 .9°, diagonal viewing angle: 106.5°4mm:Horizontal viewing angle: 75.1°, vertical viewing angle: 41.5°, diagonal viewing angle: 88.7°M12 Lens MountDORI 2.8mm Distance:Detect: 60m (197ft)Observe: 25m (82ft)Detect: 12m (39 feet)Identification: 6 m (20 ft)4 mm:Detection: 80 m (262 ft)Note: 33 m (109 ft)Identify: 16 m (52 ??feet)Identification: 8 m (26 feet)VIDEOmax. Resolution 2560 × 1440Main Stream Frame Rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps br /Resolution: 2560x1440,2304x1296, 2048x1280, 1920x1080, 1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 frames per second.Substream frame rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 640x480,352x288, 320x240Note: If the rotationpicture set to 90° or 270°, the frame rate only supports up to 20 frames per second.Bitrate control CBR, VBRVideo compression Mainstream: H.265+/H.265/H.264 +/H.264Substream: H.265/H.264Type H.264 Main Profile/High ProfileSupported Main Stream H.264+Type Main Profile H .265H.265+ Main Stream SupportedVideo Bit Rate Main Stream: 256 Kbps to 4 MbpsSub Stream: 64 Kbps to 512 KbpsLIGHTERIR LED Quantity: 2Range: 30mWavelength: 850nmWhite LED N/AIlluminator On/Off Control Auto/Scheduled/Always On/ Always OffANGLE ADJUSTMENT (MANUAL)Pan Range: 0° to 355°Tilt: 0° to 75°PICTUREImage settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,White balance, IR protection, HLC, adjustable via client software, rotation (90°/270 °)Image enhancement BLC/3D DNR/HLC/SmartIRWide dynamic range DWDRSNR ? 52 dBImage parameters switch YesPrivacy mask Up to 4 masks ROI 1 RegionOSD Setup YesAUDIOAudio Communication N/AAudio Input Not AvailableAudio Output N/AAudio Compression N/AAudio Sampling Rate N/AEnvironmental Noise Filtering N/AAudio Bitrate Not AvailableNETWORK Security Password Protection, HTTPS Encryption, IP Address Filter, AuthenticationProtocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS,RTSP, NTP , UPnP UDP, SSL/TLSONVIF APISimultaneous live view 3 main streams and 3 sub streamsVIGI client application, VIGI security manager, VIGI NVR, webGoogle web browser Chrome® 57 and aboveFirefox® 52 and aboveSafari® 11 and aboveMicrosoft® Edge 91 and aboveCloud YesONVIF YesINTERFACESNetwork interface 1 RJ45 10/100M self-adaptive Ethernet portAlarm N/ANo reset button availablePower supply DC Power PortButton -Video Out -Built-in Storage N/ABuilt-in Microphone N/ABuilt-in Speaker N/AAudio Not AvailableALARM AND EVENT MANAGEMENTSmart event classification of people and vehicles, area intrusion detection, line crossing detection, people detection, vehicle detection, region entry detection, region exit detection, abandoned object detection , object removal detectionBasic event motion detection, video tamper detection, exception (illegal login)Alarm Linkage Message PushLinkage Method N/AOutput Notification Push MessageGENERALPackage Contents VIGI Network CameraQuick Start GuideWaterproof Cable ConnectorsMounting AccessoriesWorking Temperature -30 -60 °CStorage temperature -40-60 °CStorage humidity 95% or less (non-condensing)Operating humidity 95% or less (non-condensing)Dimensions (H X W X D) 115 × 115 × 86mmMaterial PlasticGeneral Features: Dual Stream, Mirror, Privacy Masks, Email Password Reset, HTTP ListeningNet Weight 0.27 kgGross weight 0.45 kgPower consumption 12V DC: Max 5WPoE: class 0Power supply 12V DC ± 5%, 5.5 mm coaxial power plugPoE (802.3af/at, class 0)Vandal resistant IK10Protection IP67, IK10Product dimensions (L x W x H) 115 × 86 × 115 mmCertificates CE/BSMI/VCCI/ONVIFVIDEO/PICTUREVideo kompression Mainstream: H.265+/H.265/H.264+/H.264Substream: H.265/H.264Frame rate and resolution Mainstream:Speed frames: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2560x1440,2304x1296, 2048x1280, 1920x1080, 1280x720Substream:Framerate: 1fps, 5fps, 10fps, 15 fps , 20fps, 25fps, 30fpsResolution: 640x480,352x288, 320x240max. Resolution 4 MP (2560 × 1440)Video Streaming Main StreamSub StreamImage Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, adjustable by client software, rotation (90°/270°)Image enhancement BLC/3D DNR/HLC/SmartIRVideo bit rate 64 Kbps to 4 MbpsDay/Night Day/Night/Auto/Schedule br /SET OF SMART FUNCTIONSSmart classification of human and vehicle events, intrusion detection, line crossing detection, people detection, vehicle detection, region entry detection, region exit detection, abandoned detection object, object removal detectionBasic event motion detection, camera tamper detection, exception (illegal login)Connection mode trigger notification: ONVIF, HTTPSRegion of interest 1 Region
