HikVision 4-Port 100Mbps RJ45 PoE (60W) 2x 100Mbps RJ45 Unmanaged Switch
Proizvod nije dobavljiv. Potražite neke druge modele koji su zamijenili HikVision 4-Port 100Mbps RJ45 PoE (60W) 2x 100Mbps RJ45 Unmanaged Switch
| Proizvođač: | Hikvision |
| Šifra: | 1340687 |
| Kataloški broj: | DS-3E0106HP-E |
| Jamstvo: | 24 |
Prosječna ocjena:
0,00
| Glasova:
0
|
| Ocijeni
ovaj proizvod
|
HikVision DS-3E0106HP-E, 6-Port Fast Ethernet PoE Switch. (1x 10 100Mbps RJ45 802.3af at bt High Power PoE 3x 10 100Mbps RJ45 PoE 2 x 10 100Mbps RJ45 ports. Switching Capacity 1.2 Gbps, Packet Forwarding Rate 0.893 Mpps. Max.Power Port 1: 60 W Ports 2 to 4: 30 W. PoE Power Pudget 60W. Dimension 145 mm 25.6 mm 68.45 mm. Working Modes-. Standard mode (default); Extend mode
4 Port Fast Ethernet Unmanaged POE Switch
Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.
ort Number1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports
Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
Working ModeStandard mode (default); Extend mode
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding ModeStore-and-forward switching
Ports for Long-Distance TransmissionPorts 1 to 4
MAC Address Table2 K
Internal Cache768 Kbits
Switching Capacity1.2 Gbps
Packet Forwarding Rate0.893 Mpps
High Priority PortsPorts 1 to 2
PoE Power Supply
PoE Standard
Port 1: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 2 to 4: IEEE 802.3af, IEEE 802.3at
PoE Power Pin
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE PortPorts 1 to 4
Max. Port Power
Port 1: 60 W
Ports 2 to 4: 30 W
PoE Power Budget60 W
Dialing Function
Long RangePorts 1 to 4: up to 300 m; and the speed rate of the port is 10 Mbps.
General
Dimension (W × H × D)145 mm × 25.6 mm × 68.45 mm (5.7” × 1.0” × 2.7”)
Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
Storage Humidity5% to 95% (no condensation)
Gross Weight0.77 kg (1.70 lb)
Net Weight0.24 kg (0.53 lb)
Power Consumption in Idle5 W
ShellMetal material, fan-free design
Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
Operating Humidity5% to 95% (no condensation)
Power Supply48 VDC, 1.35 A
Max. Power Consumption65 W
| Osnovne karakteristike | |
|---|---|
| Portova: | 5 |
| Brzina prijenosa podataka: | 100 Mbps |
| Kućište: | Stolno |
| POE: | Da |
| Konektori | |
| SFP: | Ne |
