CPU Support for an Intel® Core™ i7 series processor in the LGA 1366 package(Go to CPU Support List for the latest CPU support ) L3 cache varies with CPU QPI 4.8GT/s / 6.4GT/s Chipset North Bridge: Intel® X58 Express Chipset South Bridge: Intel® ICH10R Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (Note 1) Dual/3 channel memory architecture Support for DDR3 2000+/1333/1066/800 MHz memory modules (Go to Memory Support List for the latest memory support list.) Audio Realtek ALC888 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In LAN 1 x Realtek 8111D chips (10/100/1000 Mbit) Expansion Slots 2 x PCI Express x16 slots, running at x16 x16(The PCI Express slots conform to PCI Express 2.0 standard.) 1 x PCI Express x4 slot 2 x PCI Express x1 slot 2 x PCI slots Storage Interface South Bridge: 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices 2x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1 and JBOD iTE IT8720 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive IEEE 1394 T.I. TSB43AB23 chip Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a brackets connected to the internal IEEE 1394a headers) USB Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 8 x SATA 3Gb/s connectors 1 x CPU fan header 3 x system fan headers 1 x power fan header 1 x North Bridge fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x IEEE 1394a headers 1 x serial port header 1 x power LED header 1 x chassis intrusion header 1 x clearing CMOS jumper Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x coaxial S/PDIF Out connector 1 x optical S/PDIF Out connector 2 x IEEE 1394a port 8 x USB 2.0/1.1 ports 1 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone) I/O Controller iTE IT8720 chip H/W Monitoring System voltage detection CPU/System/North Bridge temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control (Note 2) BIOS 2 x 8 Mbit flash Use of licensed AWARD BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b Unique Features Support for @BIOS Support for Q-Flash Support for Virtual Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune (Note 3) Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share Bundle Software Norton Internet Security (OEM version) Operating System Support for Microsoft® Windows Vista/XP Form Factor ATX Form Factor; 30.5cm x 24.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website. Note (Note 1) Due to Windows Vista/XP 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.(Note 2) Whether the CPU/system fan speed control function is supported will depend on the CPU/ system cooler you install.(Note 3) Available functions in EasyTune may differ by motherboard model.
