5MP super high resolution and 24-hour full colorPeople and vehicle analyticsPeople and vehicle classificationSmart detectionSmart video enhancement technologyActive defense and two-way soundIP67 waterproofH.265+ compression technology
CAMERAImage sensor 1/2.7” CMOS with progressive scanShutter speed 1/3 to 1/10000 sSlow shutter YesMinimum illumination 0.005 lux; 0 lux with IR/white lightDay/night mechanism IR Cut FilterDay/night switching unified/scheduled/automaticLENSLens type with fixed focusFocal length 2.8/4mmAperture F1.6FOV • 2.8mm:Horizontal angle of view: 111.4°, vertical angle of view : 58.8°, diagonal viewing angle: 134°• 4mm:Horizontal viewing angle: 88°, vertical viewing angle: 46°, diagonal viewing angle: 105.4° Lens Mount M12*P 0.5DORI Distance • 2.8mmDetection: 64m (210ft)Regard: 27m (89ft)Identify: 13 m (43 ft)Identification: 6 m (20 ft)• 4 mmDetection: 80 m (262 ft)Note: 33 m (108 ft)Identify: 16 m (52 ??feet)Identify: 8 m (26 feet)Angle adjustment (manual)Pan range: 0° to 360°, Tilt: 0 ° to 85°, Rotation: 0° to 360°ILLUMINATORIR LED • Quantity: 4• Range: 30m• Wavelength: 850nmWhite LED • Quantity: 4• Range: 30mIlluminator On/Off Control Auto/Scheduled/Always On/Always OffVIDEOmax. Resolution 2880 X 1620Main Stream • Frame Rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps • Resolution:2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080,1280x720• Note:If the image rotation is set to 90° or 270°, the speed frames only supports up to 20fps.Substream • Frame rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps , 25fps, 30fps• Resolution:704x576,640x480, 352x288, 320x240• Note:If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 frames per second.Bitrate control CBR, VBRVideo compression • Mainstream: H.265+/H.265/H.264+/H.264• Substream: H .265/H.264H.264 High ProfileH.264+ Mainstream SupportedH.265* Mainstream ProfileH.265+ Mainstream Supported* Video Bitrate • Mainstream: 256Kbps to 6Mbps• Substream: 64Kbps to 512KbpsPicturePicture Settings• Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Avoid overexposure to infrared• HLC configurable via client softwareImage enhancement BLC/3D DNR/HLC/SmartIR120dB wide dynamic rangeNote: When human and vehicle analytics are enabled, only DWDR is supported .SNR ? 52 dBPicture Parameter Switch YesPrivacy Mask Up to 4 MasksROI 1 RegionOSD Setup YesAUDIOAudio communication Two-way audioAudio input YesAudio output YesAudio compression YesSound sampling rate 8KHzEnvironmental noise filtering YesAudio bit rate 64 Kbps (G.711 alaw)NETWORKProtocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARPONVIF YesAPI Open Network Video Interface (S/T/G profile)Simultaneous Live View 3 main streams and 3 sub streamsVIGI Client Application, VIGI Security Manager, Web UI, VIGI VMSWeb Browser • Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and aboveCloud YesSecurity Protection with password, HTTPS encryption, IP address filter, AuthenticationALARM AND EVENT MANAGEMENTSmart event • Intrusion detection• Line crossing detection• Region entry detection• Region exit detection• Abandoned object detection• Object removal detection• Idleness detection• People detection • Vehicle detection• Abnormal audio detection• Scene change detectionBasic event • Motion detection (enhanced with human and vehicle classification for more accurate alerts)• Video tampering detection• Exception (illegal login)Alarm connection • Video recording to memory card• Push messages• Sound warning• Flashing white lightConnection method N/ AOutput notification Push messageDeep learning featurePeople and vehicle analytics Search and filter people or vehicles of interest based on many different attributes, making your event search faster and easier .INTERFACESNetwork interface 1 RJ45 10/100M self-adaptive Ethernet port, PoEAlarm N/AReset button YesPower DC Power PortBuilt-in storage, built-in memory card slot, MicroSD card support, up to 512GB**Built-in microphone Yes; Records everything that happens within 15 ft of the cameraBuilt-in speaker YesAudio is not availableGENERALOperating temperature -30-60 ° CStorage temperature -40-60°COperating humidity 95% or less (non-condensing)Storage humidity 95% or less (non-condensing)Package contents • VIGI Network Camera• Quick Start Guide• Waterproof Cable Connectors• Mounting AccessoriesMaterial MetalNet Weight 0.48kgPower supply • 12V DC ± 5%, max. 11 W, 5.5 mm coaxial power plug• PoE: 802.3af/at, class 0, max. 12 WProtection IP67Product dimensions (L x W x H) 111 × 111 × 83.7 mmCertificates CE, NTRA, VCCI, KC, BSMI, FCC, IC
