Scalable charging capacity up to 22 kW
• Charging socket (type 2) for charging cable
• Digital management and remote control with

Webasto ChargeConnect (access via portal and app)
• Always online thanks to 24/7 real-time transmission of the wallbox data to Webasto ChargeConnect
• Authentication using RFID technology or

Webasto ChargeConnect App
• Interface for Energy Management System (EMS) integration via Modbus TCP1)
• Integrated local dynamic load management2) for up to 32 charging points Integrated MID-compliant meter allows billing and refund of charging processes? • Meter window for easy reading of energy meter values
• Robust, high-quality housing meeting the Webasto quality and safety standards
• Cost savings at installation due to DC residual current protection
• Secured network stability by network operator using a ripple control receiver
• User friendly configuration using an integrated configuration hotspot and Webasto Charger Setup App or configuration interface for installers?
• Cellular connectivity ready on board via micro SIM card3)

Specifications
- Authorization
• Application
• Wi-Fi
• RFID
- Charging plug: Type 2
- Charging current: 32
- Charging power: 22 kW
- Nominal voltage: 230 V 400 V
- Type of protection:
• IP54
• IK10
- Color:Black
- Width: 315 mm
- Height: 460 mm
- Depth: 135 mm
- Weight: 5 kg
- Number of connections: 1
- Number of phases: 1-phase and 3-phase
- Nominal current: 32
- Max. temperature: +55 °C
- Min. temperature: -35 °C
- Product type: Wallbox
